Core Hardware Specifications
- Graphics Engine: NVIDIA GeForce RTX 5080
- Architecture: Blackwell (GB203)
- CUDA Cores / Shaders: 10,752
- AI Performance: 1801 TOPs
- Video Memory: 16GB GDDR7
- Memory Interface: 256-bit
- Memory Speed: 30 Gbps
- OC Mode Boost Clock: 2685 MHz
- Default Mode Boost Clock: 2655 MHz
Connectivity & Resolution
- Display Outputs: 3x Native DisplayPort 2.1b, 1x Native HDMI 2.1b
- Max Digital Resolution: 7680 x 4320
- HDCP Support: Yes (2.3)
Physical & Power Requirements
- Bus Standard: PCI Express 5.0
- Power Connectors: 1x 16-pin power connector
- Recommended PSU: 850W
- Slot Size: 2.5-slot (SFF-Ready compatible)
- Dimensions: 304 x 126 x 50 mm
