Core & Clock Specifications
- Total Cores / Threads: 24 / 24
- Performance Cores (P-cores): 8 (Base 3.7 GHz, Max Turbo up to 5.5 GHz)
- Efficient Cores (E-cores): 16 (Base 3.2 GHz, Max Turbo up to 4.7 GHz)
- Unlocked Multiplier: Yes (for easy overclocking)
- Intel Smart Cache (L3): 36 MB
- Total L2 Cache: 40 MB
- Processor Base Power (PBP): 125 W
- Maximum Turbo Power (MTP): 250 W
- Socket Type: FCLGA1851
- Compatible Chipsets: Z890, B860, W880, Q870, H810
- Memory Support: Dual-channel DDR5 up to 7200 MT/s
- PCI Express Lanes: PCIe Gen 5 and Gen 4 support
- Integrated Graphics: Intel Graphics (Arc Xe-LPG, 4 Xe-cores, up to 2.0 GHz)
- NPU (AI Boost): Intel AI Boost delivering 13 NPU TOPS (approx. 36 total system TOPS)
