Core Configuration & Speeds
- Total cores: 12 (8 Performance-cores and 4 Efficient-cores)
- Total threads: 20
- Performance-core base/max turbo frequency: 3.60 GHz / 4.90 GHz
- Efficient-core base/max turbo frequency: 2.70 GHz / 3.80 GHz
- Intel Turbo Boost Max Technology 3.0 frequency: Up to 5.00 GHz
- Intel Smart Cache (L3): 25 MB
- Total L2 cache: 12 MB
- Processor base power (TDP): 125 W
- Maximum turbo power: 190 W
- Socket: LGA 1700
- Compatible chipsets: Intel 600 and 700 series (Z690, H670, B660, H610, etc.)
- Memory support: Up to DDR5 4800 MT/s or DDR4 3200 MT/s
- PCI Express lanes: Up to 20 lanes (Gen 5 and Gen 4 support)
- Overclocking: Fully unlocked multiplier (K-series)
