Core & Clock Details
- Total Cores: 16 (8 P-cores + 8 E-cores)
- Total Threads: 24
- P-Core Base Frequency: 3.40 GHz
- E-Core Base Frequency: 2.50 GHz
- P-Core Max Turbo Frequency: Up to 5.30 GHz
- E-Core Max Turbo Frequency: Up to 4.20 GHz
- Max Turbo Boost 3.0 Frequency: 5.40 GHz
- Intel Smart Cache (L3): 30 MB
- L2 Cache: 24 MB
- Base Power (TDP): 125 W
- Maximum Turbo Power: 253 W
- Socket Type: LGA1700 (Compatible with Intel 600 and 700 series chipsets)
- Integrated Graphics: None (Requires a dedicated graphics card; indicated by the "F" suffix)
- Overclocking: Fully unlocked (indicated by the "K" suffix)
- Memory Support: Up to DDR5 5600 MT/s or DDR4 3200 MT/s
- PCI Express Lanes: Up to 20 lanes (Gen 5.0 and 4.0)
