Core and Clock Details
- 20 cores total: 8 Performance-cores (P-cores) and 12 Efficient-cores (E-cores).
- 20 threads (no hyperthreading on P-cores).
- P-core base frequency: 3.90 GHz.
- P-core max turbo frequency: Up to 5.40 GHz.
- Max turbo boost frequency (Intel Turbo Boost Max 3.0): Up to 5.50 GHz.
- E-core base frequency: 3.30 GHz.
- E-core max turbo frequency: Up to 4.60 GHz.
- Intel Smart Cache (L3): 30 MB.
- L2 Cache: 36 MB.
- Base Power (TDP): 125 W.
- Maximum Turbo Power: 250 W.
- Unlocked multiplier for overclocking (K-series designation).
- CPU Socket: LGA 1851.
- Supported Chipsets: Intel 800-series (such as Z890, B860).
- Memory Types: Dual-channel DDR5.
- Integrated Graphics: None (requires a dedicated graphics card, denoted by the "F" suffix).
- PCIe Lanes: PCI Express 5.0 and 4.0 supported.
