Core Hardware Specifications
- CPU Support: AMD Socket AM5 for Ryzen™ 9000, 8000, and 7000 series desktop processors
- Chipset: AMD B650
- Form Factor: Micro-ATX (9.6 inches x 9.6 inches / 24.4 cm x 24.4 cm)
- Memory: 4 x DIMM slots, max 256GB, DDR5 supporting overclocking speeds (6400+ MT/s) and AMD EXPO
- Power Design: 12+2 (60A) power stages with enlarged VRM heatsinks
- Expansion Slots: 1 x PCIe 4.0 x16 slot (for Ryzen 9000/7000) plus additional PCIe slots
- M.2 Slots: 2 total M.2 slots (supports PCIe 5.0 and PCIe 4.0 storage variants depending on configuration)
- SATA Ports: 4 x SATA 6Gb/s ports
- Ethernet: 1 x Realtek 2.5Gb Ethernet with TUF LANGuard
- Wireless (WiFi variant only): Wi-Fi 6 (802.11 a/b/g/n/ac/ax) and Bluetooth v5.2
- USB Ports: Rear panel includes 1 x USB 3.2 Gen 2x2 Type-C®, 2 x USB 3.2 Gen 2, and additional USB ports
- Video Outputs: 1 x DisplayPort, 1 x HDMI port
- Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
