Key Specifications
- CPU Socket: LGA 1700 (Supports Intel Core 14th/13th/12th Gen, Pentium Gold, and Celeron)
- Chipset: Intel H610
- Form Factor: Micro-ATX (23.6 cm x 20 cm / 9.3 in x 7.9 in)
- Memory (RAM): 2x DDR4 DIMM slots, up to 64GB, supporting speeds up to 3200 MHz (JEDEC)
- Expansion Slots:
- 1x PCIe 4.0 x16 slot (from CPU)
- 1x PCIe 3.0 x1 slot (from chipset)
- Storage:
- 1x M.2 slot (Key M, PCIe 3.0 x4, supports 2242/2260/2280 devices)
- 4x SATA 6Gb/s ports
- Display Outputs:
- 1x HDMI 1.4 port (supports up to 4K 30Hz)
- 1x VGA port (supports legacy resolutions up to 2048x1536)
- USB Ports:
- Rear: 2x USB 3.2 Gen 1 5Gbps Type-A, 4x USB 2.0
- Front headers support an additional 2x USB 3.2 Gen 1 and 4x USB 2.0
- Audio & Networking: Realtek ALC897 7.1-channel HD audio codec; Realtek RTL8111H Gigabit LAN
