Core Specifications
- Graphics Engine: NVIDIA GeForce RTX 3070 (GA104-302-A1 / Ampere)
- CUDA Cores / Shading Units: 5,888
- Video Memory: 8GB GDDR6
- Memory Interface: 256-bit
- Memory Bandwidth: 448.0 GB/s
- Bus Standard: PCI Express 4.0
Clock Speeds & Performance
- Boost Clock: ~1725 MHz (Gaming Mode) up to 1770+ MHz (OC Mode variant dependant)
- Memory Clock: 1750 MHz (14 Gbps effective)
- Ray Tracing Cores: 46 (2nd Generation)
- Tensor Cores: 184 (3rd Generation)
- TDP (Power Consumption): 220 W
- Recommended PSU: 550 W minimum
- Display Outputs: 1x or 2x HDMI 2.1, 3x DisplayPort 1.4a
- Cooling: Triple-fan design
