Processor & Chipset
- CPU Socket: LGA 1700
- CPU Support: Intel 14th, 13th, and 12th Generation Core, Pentium Gold, and Celeron processors
- Chipset: Intel B760
- Slots: 2x DDR5 DIMM slots (Dual-channel)
- Capacity: Up to 128GB
- Speeds: Supports up to 6400+ MHz (OC) / 5600 JEDEC
- Features: Intel XMP 3.0 OC support
- PCIe x16 Slot: 1x PCIe 4.0 x16 slot (Steel Armor equipped)
- PCIe x1 Slot: 1x PCIe 3.0 x1 slot
- Display Outputs: 1x HDMI 1.4 (supports up to 4K @ 30Hz) and 1x VGA (requires processor graphics)
- M.2 Slots: 1x Lightning Gen4 x4 64Gbps slot (supports PCIe 4.0 x4 / SATA mode, sizes 2280/2260/2242)
- SATA Ports: 4x SATA 6Gbps ports
- LAN: Realtek RTL8111H Gigabit LAN
- Audio: Realtek ALC897 8-Channel (7.1) HD Audio with Audio Boost
- USB 3.2 Gen 1 (5Gbps): 4 total (2 on rear Type-A, 2 via internal headers)
- USB 2.0: 8 total (4 on rear Type-A, 4 via internal headers)
- Form Factor: Micro-ATX (mATX)
