Core Specifications
- CPU Socket: LGA 1700 (Supports 12th, 13th, and 14th Gen Intel Core, Pentium, and Celeron)
- Chipset: Intel Z790
- Form Factor: ATX
- Memory Support: 4x DDR5 DIMM slots, max up to 192GB, supporting speeds up to 7800+ MHz (OC)
- Power Delivery: 18+1+1 Phase design with 90A SPS / DrMOS
- Expansion Slots:
- 1x PCIe 5.0 x16 slot
- 1x PCIe x16 slot (supports PCIe 4.0 x4)
- 1x PCIe 4.0 x4 slot
- 1x PCIe 3.0 x1 slot
- Storage: 4x PCIe 4.0 x4 M.2 NVMe SSD slots, 6x SATA 6Gb/s ports
- Networking: 2.5G Ethernet LAN, Wi-Fi 6E, Bluetooth 5.3
- Rear I/O USB Ports: USB 3.2 Gen 2x2 Type-C (20Gbps), USB 3.2 Gen 2 Type-A, and USB 3.2 Gen 1 ports
- Video Outputs: DisplayPort, HDMI (exact versions vary by sub-revision)
