Core Specifications
- Slots: 2x DDR5 DIMM slots
- Max Capacity: 128GB
- Speeds Supported: Up to 6800+(OC) / 6000(OC) / 4800 (JEDEC) MHz
- Profiles: Supports AMD EXPO and Dual-Channel mode [1]
- PCIe x16 Slot: 1x PCIe 4.0 x16 slot (supports up to x16 for Ryzen 9000/7000, x8 for 8700/8600/8400, x4 for 8500/8300)
- PCIe x1 Slot: 1x PCIe 3.0 x1 slot [1]
- M.2 Slots: 1x M.2 Gen 4 x4 slot (supports 2280/2260 form factors via CPU)
- SATA Ports: 4x SATA 6Gbps ports (supports RAID 0, 1, 10)
- Rear USB: 4x USB 5Gbps Type-A ports, 2x USB 2.0 ports
- Display Outputs: 1x HDMI 2.1 (4K at 60Hz), 1x VGA port (requires CPU with integrated graphics)
- LAN: Realtek RTL8111H Gigabit LAN
- Audio: Realtek ALC897 7.1-Channel High Definition Audio
