Core Specifications
- CPU Support: Intel LGA1851 socket for Intel Core Ultra Processors (Series 2)
- Chipset: Intel B860
- Form Factor: Micro-ATX (mATX)
- Slots: 2 x DIMM slots (Dual Channel)
- Capacity: Max 128GB DDR5
- Speed: Up to 8800+ MT/s (OC), supports CUDIMM, XMP, and AEMP III
- M.2 Slots: 2 slots total (including PCIe 5.0 and PCIe 4.0 support)
- SATA Ports: 4 x SATA 6Gb/s ports
- Expansion Slots: 1 x PCIe 4.0 x16 slot and 2 x PCIe 4.0 x1 slots
Networking & Connectivity
- Ethernet: 1 x Realtek 2.5Gb Ethernet with ASUS LANGuard
- Wireless: Wi-Fi 6 (802.11ax, 1x1)
- Bluetooth: Yes (Bluetooth version may vary by module)
- Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
- Display Output: 1 x HDMI port (supporting 4K @ 60Hz as specified in HDMI 2.1)
