Processor & Chipset
- CPU Socket: LGA 1700 (Supports Intel 12th, 13th, and 14th Generation Core, Pentium, and Celeron processors)
- Chipset: Intel Z690 Express
- Slots: 4 x DDR4 DIMM sockets
- Capacity: Up to 128 GB system memory
- Type: Dual-channel, Non-ECC, unbuffered DDR4 memory
- PCIe x16: 1 x PCI Express 5.0 x16 slot (from CPU)
- PCIe x4 / x1: 2 x PCI Express 3.0 x16 slots (running at x4) and 1 x PCIe 3.0 x1 slot (depending on exact revision)
- M.2 Slots: 3 x M.2 connectors (NVMe PCIe 4.0 x4/x2), equipped with Thermal Guard heatsinks
- SATA: 6 x SATA 6Gb/s ports
- Rear USB:
- 1 x USB Type-C port with USB 3.2 Gen 2x2 support (up to 20Gb/s)
- 1 x USB 3.2 Gen 2 Type-A port (red)
- 2 x USB 3.2 Gen 1 ports
- 4 x USB 2.0/1.1 ports
- Networking: Realtek 2.5 GbE LAN chip
- Video Outputs: 1 x DisplayPort, 1 x HDMI port
- VRM Design: 16+1+2 Twin Hybrid Phases Digital Power Design with 60A Power Stage
- Power Connectors: 1 x 24-pin ATX main connector, 1 x 8-pin and 1 x 4-pin ATX 12V power connectors
- Audio: High Definition Audio (8-channel) with audio noise guard
