Core Specifications
- CPU Socket: LGA 1200 (10th & 11th Gen Intel Support)
- Chipset: Intel Z590
- Form Factor: Micro-ATX (24.4 cm x 24.4 cm)
- Memory Support: 4 DIMM slots, up to 128GB DDR4-5066MHz (OC)
- Graphics Slot: 1x PCIe 4.0 x16 slot
- Expansion Slots: 2x PCIe 3.0 x1 slots
- Storage Ports: 6x SATA 6Gb/s ports and M.2 slots (PCIe 4.0 support)
- Networking: Realtek 8125B 2.5Gbps LAN controller
- Display Outputs: HDMI 2.0b, DisplayPort 1.4, and VGA (requires processor graphics)
- USB Ports: USB 3.2 Gen 2 and USB 2.0 ports (varying front and rear panel headers)
