Core Specifications
- CPU Socket: LGA 1700, compatible with Intel Core 14th, 13th, and 12th generation, Pentium, and Celeron processors
- Chipset: Intel H610 Express
- Form Factor: Micro-ATX (22.3cm x 21.5cm)
- Slots: 2 x DDR4 DIMM sockets
- Capacity: Up to 64 GB total (32 GB single DIMM capacity)
- Speeds: Support for up to DDR4 3200/3000/2933/2666/2400/2133 MT/s
- Architecture: Dual channel, supports XMP memory modules
- PCIe x16: 1 x PCI Express x16 slot, running at PCIe 4.0
- PCIe x1: 1 x PCI Express x1 slot (running at PCIe 3.0)
- M.2 Slot: 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)
- SATA Ports: 2 x SATA 6Gb/s connectors
- USB Ports: Rear and internal headers supporting USB 3.2 Gen 1 and USB 2.0/1.1
- LAN: Realtek GbE LAN chip (1 Gbps) with bandwidth management
- Audio: Realtek Audio CODEC supporting 2/4/5.1/7.1-channel high-definition audio
- Video Outputs: 1 x HDMI port (supporting max resolution of 4096x2160 @ 60 Hz)
