Core Specifications
- CPU Socket: LGA 1700 (Supports 12th/13th/14th Gen Intel Core)
- Chipset: Intel B760
- Form Factor: Mini-ITX (170 mm x 170 mm)
- Memory Support: 2x DDR4 DIMM slots, up to 64GB total, speeds up to 5333+ MHz (OC)
- Expansion Slots: 1x PCIe 5.0 x16 slot
- Storage: M.2 slots (Lightning Gen 4 x4) with M.2 Shield Frozr
- Networking: Realtek 2.5G LAN, Intel Wi-Fi 6E, Bluetooth 5.3
- Graphics Outputs: HDMI, DisplayPort
- Power Design: Direct 8+1+1 phase power design with 90A DrMOS
