Core Specifications
- CPU Support: Intel® Core™ 14th, 13th, and 12th Gen Processors, Intel® Pentium® Gold, and Celeron® Processors (LGA 1700)
- Chipset: Intel® Z790
- Form Factor: ATX (30.5 cm x 24.4 cm)
- Memory Support: 4x DIMMs, Max 256GB, up to 7200+ MHz (OC); supports Intel XMP 3.0
- Power Design: 14+1+1 DRPS with 55A DrMOS and dual 8-pin CPU power connectors
- PCIe Slots: 1x PCIe 5.0 x16 slot, 1x PCIe 4.0 x16 slot, 2x PCIe 3.0 x1 slots
- M.2 Storage: Multiple Lightning Gen 4 x4 slots with M.2 Shield Frozr thermal solutions
- SATA Ports: 6x SATA 6Gb/s ports
- Networking: Realtek 2.5G LAN Controller
- USB Ports: Rear USB 3.2 Gen 2x2 (Type-C), multiple USB 3.2 Gen 2 and Gen 1 ports
- Video Output: 1x HDMI™ 2.1 (supports 4K 60Hz), 1x DisplayPort
- Audio: Realtek® Audio Codec with 7-Channel High Definition Audio
